PostgreSQL Logical Decoding Plugins: pgoutput vs wal2json

A Simple Example: See an Update Flow End-to-End

To understand how different output plugins work, let's start with a concrete scenario. We'll set up logical replication, make a change, and see how different plugins format that change.

Setting Up Logical Replication

First, enable logical replication in PostgreSQL by checking your WAL level:

SHOW wal_level;

If it's not set to 'logical', configure logical replication for your PostgreSQL provider (AWS RDS, Google Cloud SQL, Azure).

Create a Table and Replication Slot

`-- 1. Create a test table CREATE TABLE users ( id SERIAL PRIMARY KEY, name VARCHAR(255) NOT NULL, email VARCHAR(255) NOT NULL, created_at TIMESTAMP DEFAULT NOW() );

-- 2. Set replica identity for complete change tracking ALTER TABLE users REPLICA IDENTITY FULL;

-- 3. Insert initial data INSERT INTO users (name, email) VALUES ('John Doe', 'john@example.com');

-- 4. Create a publication CREATE PUBLICATION user_changes FOR ALL TABLES;

-- 5. Create logical replication slot with test_decoding plugin SELECT pg_create_logical_replication_slot('test_slot', 'test_decoding');`

Make the Change We're Tracking

-- The change we'll observe across different plugins UPDATE users SET name = 'John Smith' WHERE id = 1;

Reading Changes from the Replication Slot

-- View the formatted output SELECT lsn, xid, data FROM pg_logical_slot_peek_changes('test_slot', NULL, NULL);

This simple update produces dramatically different output depending on your chosen plugin—a critical factor for automated data sync between applications and integration complexity.

How Changes Flow from Table to Output Plugin

Understanding the data flow helps optimize your real-time data synchronization architecture:

1. Write-Ahead Log (WAL) Storage

PostgreSQL's WAL stores low-level binary records, not human-readable messages:

# Simplified WAL record structure WAL Record: LSN 0/1A2B3C4 - Relation OID: 16384 (internal table identifier) - Transaction ID: 12345 - Operation: UPDATE - Block/offset: physical storage location - Old tuple: [binary data for old row] - New tuple: [binary data for new row]

The WAL contains only internal identifiers and binary data—no table names, column names, or readable values.

2. Logical Decoding Process

This architecture allows PostgreSQL to support many output formats without changing the underlying WAL format or storing duplicate information. The core database only needs to log changes once in the WAL, and then any number of output plugins can decode those logs and present the data in JSON, SQL, binary, etc., as needed.

The decoding process:

• 01Reads WAL records sequentially from slot position (LSN)
• 02Resolves internal identifiers using system catalogs
• 03Transforms binary data into logical representation
• 04Assembles complete transactions in commit order
• 05Passes structured data to the output plugin

3. Plugin-Specific Formatting

Every logical decoding plugin receives the same core information about the change; what differs is how they output it. The test_decoding plugin formats this as human-readable text, wal2json converts it to JSON, and pgoutput encodes it in PostgreSQL's binary logical replication protocol.

Each plugin receives identical decoded information:

• Table name: public.users
• Operation: UPDATE
• New values: {id: 1, name: "John Smith", email: "john@example.com"}
• Old values: {name: "John Doe"}

This standardized input enables consistent behavior across different output formats while supporting diverse integration requirements.

Built-in Output Plugins

PostgreSQL ships with two logical decoding plugins out of the box. These don't require any additional installations—they're ready to use on any Postgres 10+ server.

pgoutput Plugin

pgoutput is PostgreSQL's default plugin for logical replication. If you're using the built-in publish/subscribe system, you're already using this plugin behind the scenes.

Sample output (conceptual representation):

BEGIN LSN: 0/1A2B3C4 TABLE: public.users UPDATE: id[integer]=1 name[text]='John Smith' (old: 'John Doe') email[text]='john@example.com' COMMIT LSN: 0/1A2B3C4

The actual output uses a binary protocol requiring specialized parsing tools.

Technical characteristics:

• Binary format provides efficiency and compactness
• Handles complex PostgreSQL data types without information loss
• High performance with incremental streaming
• Production-ready, universally supported on managed services
• Requires specialized tools for consumption (can't use SQL functions directly)
• Binary protocol isn't human-readable for debugging

test_decoding

PostgreSQL's example plugin, primarily useful for understanding logical decoding mechanics and debugging.

Sample output:

BEGIN 12345 table public.users: UPDATE: id[integer]:1 name[text]:'John Smith' email[text]:'john@example.com' COMMIT 12345

Technical characteristics:

• Human-readable text format for easy interpretation
• Excellent for learning logical decoding concepts
• Included with PostgreSQL by default
• Useful for debugging replication issues
• Output format not designed for production parsing
• Limited functionality compared to specialized plugins
• No advanced features like filtering or sophisticated type handling

Popular Third-Party Plugins

wal2json

The wal2json extension allows streaming all changes in a database to a consumer, formatted as JSON.

Sample output:

{ "change": [{ "kind": "update", "schema": "public", "table": "users", "columnnames": ["id", "name", "email", "created_at"], "columnvalues": [1, "John Smith", "john@example.com", "2024-01-15T10:30:00"], "oldkeys": { "keynames": ["id"], "keyvalues": [1] }, "oldvalues": [1, "John Doe", "john@example.com", "2024-01-15T10:30:00"] }] }

Technical characteristics:

• Easy parsing in any programming language
• Human-readable format for development and debugging
• Supported on most managed services (Cloud SQL supports pgoutput, test_decoding, and wal2json)
• Higher overhead than binary formats
• Performance degradation with very large transactions

decoderbufs

Uses Protocol Buffers for efficient binary serialization, targeting high-throughput scenarios.

Sample output (conceptual protobuf structure):

RowMessage { transaction_id: 12345 table: "public.users" op: UPDATE new_tuple: { columns: [ {name: "id", type: INTEGER, value: 1}, {name: "name", type: TEXT, value: "John Smith"}, {name: "email", type: TEXT, value: "john@example.com"} ] } old_tuple: { columns: [ {name: "name", type: TEXT, value: "John Doe"} ] } }

Technical characteristics:

• Very efficient binary format
• Schema-defined structure with strong typing
• Excellent for high-throughput scenarios
• Requires compilation and installation
• Not available on most managed services
• Added complexity for development teams

Specialized Plugins

• wal2mongo: Outputs MongoDB-compatible JSON operations for direct MongoDB replication
• decoder_raw: Generates raw SQL statements executable on target databases

Beyond Custom Logical Decoding Implementations

While logical decoding plugins provide the foundation for change data capture, building production-ready consumers requires significant engineering investment. Organizations implementing automated data sync between applications often face challenges that go beyond plugin selection.

Traditional logical decoding implementation challenges:

• Custom consumer development and maintenance
• API rate limiting and error handling
• Infrastructure scaling and monitoring
• Security and compliance implementation
• Bi-directional sync complexity and conflict resolution
